Category
Mobile Platform
Manufacturer
Vkoming
RoHS
YES
Certification
Delivery
Payment
| CPU | Intel® 12/13th CoreTM i3/i5/i7 or Celeron®Processor |
| Chipset | Intel® SOC |
| Memory | 2*SO-DIMM DDR5 4800MHz Max 64GB |
| Storage | 1*SATA3.0 / 1*M.2 Key M (Supports SATA3.0&PCIe X4 adaptive) |
| Expansion Interface | 1*M.2 Key E (Supports WiFi+Bluetooth extension, supports CNVI and WiFi6) |
| BIOS | AMI BIOS |
| System | Windows 10/11 32bit/64bit/Linux |
| Ethernet | 1/2*Intel i226-V 2.5GBE Controller,RJ45 |
| USB | 3*USB3.0;2/4*USB2.0;1*Type-C USB3.0 |
| Audio | Onboard audio decoding controller ALC897 |
| Others | 1*C_FAN Header / 1*F_USB1 Header (Extensible 2*USB2.0) / 1*SATA interface |
| Display Interface | 2*HDMI / 1*Type-C (Support 3 display synchronous/asynchronous output) |
| Dimension | 100mmX106mm |
| Power Input | DC 12V-19V input power supply |
| Temperature | Operation: 0℃~60℃, Storage: -20℃~75℃ |
| Relative Humidity | 0% ~ 95%, non-condensing |
Data sheet: Work in prgress, stay tuned!
