Category
Mobile Platform
Manufacturer
Vkoming
RoHS
YES
Certification
Delivery
Payment
| CPU | Intel® 11th Tiger Lake i7/i5/i3 FCBGA1449 Processor |
| Chipset | Intel® SOC |
| Memory | 2*SO-DIMM DDR4 3200MHz Max 64GB |
| Storage | 1*SATA3.0 / 1*M.2 Key M (Supports SATA3.0 and PCIe Gen4 x4 for SSD) |
| Expansion Interface | 1*Mini PCIe (Supports Wifi+Bluetooth extension module ) 1*SIM card slot |
| BIOS | AMI BIOS |
| System | Windows 10/11 32bit/64bit/Linux |
| Ethernet | 1/2*Realtek® RTL8111 1Gbps Ethernet Controller,RJ45 |
| USB | 4*USB 3.2,5*USB 2.0,1*Type-C USB |
| Audio | Onboard audio decoding controller ALC269 (SPK support 2.2 W @ 4 Ω Max) |
| Others | 1*SPEAKER Header / 1*F_PANEL Header / 1*SATA3.0 interface |
| Display Interface | 2*HDMI / 2*DP (Support 4 display synchronous/asynchronous output) |
| Dimension | 121mmX121mm |
| Power Input | DC 12V-19V input power supply |
| Temperature | Operation: 0℃~60℃, Storage: -20℃~75℃ |
| Relative Humidity | 0% ~ 95%, non-condensing |
Data sheet: Work in prgress, stay tuned!
