Category
Mobile Platform
Manufacturer
Vkoming
RoHS
YES
Certification
Delivery
Payment
| CPU | Intel® 4/5th Generation Intel ® Core™ U-series Processor |
| Chipset | Intel® SOC |
| Memory | 1*SO-DIMM DDR3L 1600/1333/1066MHZ Max 16GB |
| Storage | 1*mSATA |
| Expansion Interface | 1*Mini PCIe (Supports Wifi+Bluetooth /4G expansion modules) |
| BIOS | AMI BIOS |
| System | Windows 7/10/11 32bit/64bit/Linux |
| Ethernet | 1*Realtek® RTL8111 1Gbps Ethernet Controller,RJ45 |
| Serial | 2*COM232 (Choose to use either JCOM2 or RJ11, with RJ11 as the default,Port RJ11 is for COM function) |
| USB | 2*USB 3.0,5*USB 2.0 |
| Audio | Onboard audio decoding controller ALC897 + NS4251 default power amplifier support 3 w @ 4 Ω; 1.7W@8Ω max |
| Others | 1*LVDS1_EDP2 / 1*EDP / 1*BKCL Header / 1*LPT_PWR Header |
| Display Interface | EDP1 / LVDS/EDP2 (Support 2 display synchronous/asynchronous output) |
| Dimension | 118mmx125mm |
| Power Input | DC 12V-24V input power supply |
| Temperature | Operation: 0℃~60℃, Storage: -20℃~75℃ |
| Relative Humidity | 0% ~ 95%, non-condensing |
Data sheet: Work in prgress, stay tuned!
