Category
PMIC - Voltage Regulators - Linear
Manufacturer
AMI Semiconductor/onsemi
RoHS
YES
Certification
Delivery
Payment
| TYPE | DESCRIPTION |
| Part Number: | NCP3337MNADJR2G |
| Description: | IC REG LIN POS ADJ 500MA 10DFN |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Package / Case | 10-VFDFN Exposed Pad |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Current - Supply (Max) | 14mA |
| Voltage - Output (Min/Fixed) | 1.25V |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Meta Part Number | NCP3337MNADJR2GOSTR-ND |
| Mounting Type | Surface Mount |
| Output Configuration | Positive |
| Number of Regulators | 1 |
| Current - Output | 500mA |
| Operating Temperature | -40°C ~ 85°C |
| Manufacturer Standard Lead Time | 20 Weeks |
| Other Names | NCP3337MNADJR2GOSTR |
| Detailed Description | Linear Voltage Regulator IC Positive Adjustable 1 Output 1.25 V ~ 10 V 500mA 10-DFN (3x3) |
| Voltage Dropout (Max) | 0.34V @ 500mA |
| Control Features | Enable, Power Good |
| PSRR | - |
| Voltage - Output (Max) | 10V |
| Output Type | Adjustable |
| Protection Features | Over Current, Over Temperature |
| Series | - |
| Current - Quiescent (Iq) | 220µA |
| Base Part Number | NCP3337 |
| Voltage - Input (Max) | 12V |
| Packaging | Tape & Reel (TR) |
| Supplier Device Package | 10-DFN (3x3) |
Data sheet: Work in prgress, stay tuned!
