Category
Embedded - Microprocessors
Manufacturer
Freescale / NXP Semiconductors
RoHS
YES
Certification
Delivery
Payment
| TYPE | DESCRIPTION |
| Part Number: | MC68302CRC20C |
| Description: | IC MPU M683XX 20MHZ 132PGA |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Series | M683xx |
| Meta Part Number | MC68302CRC20C-ND |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Voltage - I/O | 5.0V |
| Speed | 20MHz |
| USB | - |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Number of Cores/Bus Width | 1 Core, 8/16-Bit |
| Ethernet | - |
| Co-Processors/DSP | Communications; RISC CPM |
| Additional Interfaces | GCI, IDL, ISDN, NMSI, PCM, SCPI |
| Supplier Device Package | 132-PGA (34.5x34.5) |
| Base Part Number | MC68302 |
| Display & Interface Controllers | - |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Graphics Acceleration | No |
| SATA | - |
| RAM Controllers | DRAM |
| Package / Case | 132-BPGA Exposed Pad |
| Detailed Description | M68000 Microprocessor IC M683xx 1 Core, 8/16-Bit 20MHz 132-PGA (34.5x34.5) |
| Packaging | Tray |
| Security Features | - |
| Core Processor | M68000 |
Data sheet: Work in prgress, stay tuned!
