Category
PMIC - Motor Drivers, Controllers
Manufacturer
Freescale / NXP Semiconductors
RoHS
YES
Certification
Delivery
Payment
| TYPE | DESCRIPTION |
| Part Number: | MC33931EKR2 |
| Description: | IC MOTOR DRIVER PAR 32SOIC |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Detailed Description | Motor Driver CMOS Parallel 32-SOIC EP |
| Interface | Parallel |
| Meta Part Number | 568-13601-2-ND |
| Output Configuration | Half Bridge (2) |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Package / Case | 32-SSOP (0.295, 7.50mm Width) Exposed Pad |
| Other Names | 568-13601-2 "######"935312312518 "######"MC33931EKR2-ND |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Supplier Device Package | 32-SOIC EP |
| Applications | Automotive |
| Voltage - Load | 5 V ~ 28 V |
| Technology | CMOS |
| Series | - |
| Voltage - Supply | 5 V ~ 28 V |
| Packaging | Tape & Reel (TR) |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushed DC |
| Current - Output | 5A |
| Step Resolution | - |
| Base Part Number | MC33931 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Data sheet: Work in prgress, stay tuned!
