Category
Transistors - FETs, MOSFETs - RF
Manufacturer
Ampleon
RoHS
YES
Certification
Delivery
Payment
| Symbol | Parameter | Conditions | Min | Typ/Nom | Max | Unit |
| frange | frequency range | 470 | 790 | MHz | ||
| PL(1dB) | nominal output power at 1 dB gain compression | 750 | W | |||
| Test signal: DVB-T (8k OFDM) | ||||||
| VDS | drain-source voltage | 470-608 MHz band | 50 | V | ||
| Gp | power gain | 470-608 MHz band | 17 | dB | ||
| ηD | drain efficiency | 470-608 MHz band | 52 | % | ||
| PL(AV) | average output power | 470-608 MHz band | 150 | W | ||
| IMDshldr | intermodulation distortion shoulder attenuation | 470-608 MHz band | -38 | dBc | ||
| PAR | peak-to-average ratio | 470-608 MHz band | 8 | dB | ||
Data sheet: Work in prgress, stay tuned!
