Category
Transistors - Bipolar (BJT) - Single
Manufacturer
STMicroelectronics
RoHS
YES
Certification
Delivery
Payment
| TYPE | DESCRIPTION |
| Part Number: | BD140 |
| Description: | TRANS PNP 80V 1.5A SOT-32 |
| Lead Free Status / RoHS Status: | |
| Vce Saturation (Max) @ Ib, Ic | 500mV @ 50mA, 500mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 40 @ 150mA, 2V |
| Manufacturer Standard Lead Time | 38 Weeks |
| Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Detailed Description | Bipolar (BJT) Transistor PNP 80V 1.5A 1.25W Through Hole SOT-32-3 |
| Current - Collector (Ic) (Max) | 1.5A |
| Other Names | 497-6657-5 BD140ST-ND |
| Current - Collector Cutoff (Max) | 100nA (ICBO) |
| Voltage - Collector Emitter Breakdown (Max) | 80V |
| Series | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Power - Max | 1.25W |
| Base Part Number | BD140 |
| Package / Case | TO-225AA, TO-126-3 |
| Operating Temperature | 150°C (TJ) |
| Packaging | Tube |
| Supplier Device Package | SOT-32-3 |
| Transistor Type | PNP |
| Meta Part Number | 497-6657-5-ND |
| Frequency - Transition | - |
Data sheet: Work in prgress, stay tuned!
