Category
Transistors - FETs, MOSFETs - RF
Manufacturer
Ampleon
RoHS
YES
Certification
Delivery
Payment
| Symbol | Parameter | Conditions | Min | Typ/Nom | Max | Unit |
| frange | frequency range | 1 | 400 | MHz | ||
| PL(1dB) | nominal output power at 1 dB gain compression | 2000 | W | |||
| Test signal: Pulsed RF | ||||||
| VDS | drain-source voltage | PL= 2000 W[0] | 65 | V | ||
| Gp | power gain | PL= 2000 W[0] | 27 | 28.4 | dB | |
| RLin | input return loss | PL= 2000 W[0] | -13.9 | dB | ||
| ηD | drain efficiency | PL= 2000 W[0] | 69 | 72.1 | % | |
Data sheet: Work in prgress, stay tuned!
